Asus ROG STRIX XG43VQ User Manual

3-1ASUS LCD Monitor XG Series
3.1 OSD (On-Screen Display) menu
3.1.1 Howtorecongure
GameVisual
Scenery Mode
Racing Mode
Cinema Mode
RTS/RPG Mode
FPS Mode
sRGB Mode
MOBA Mode
MOVE/ENTER
User Mode
BACK
EXIT
Color
GamePlus
Input Select
System Setup
MyFavorite
PBP Setting
DisplayPort 3840x1080@ 144Hz
Racing Mode
ROG Strix XG43V HDR OFF
+
1. Press the Central of 5-way button to display the OSD menu.
2. Press the Up and Down keys to switch the options in the menu.
When you move from one icon to another, the option name is
highlighted.
3. To select a highlighted item from the menu, press the Right key or the
Central button.
4. Press the Up and Down keys to select the desired parameters.
5. Press the Right key or the Central button to enter the slide bar, and
then use the Up or Down keys (depending on the indicators in the
menu) to make changes.
6. Press the Left key to return to the previous menu.

Asus ROG STRIX XG43VQ Specifications

General

Panel Size	43.4” W (110.23 cm)
Max. Resolution	3840 x 1200
Brightness (Typ.)	450 nits (typical)
Intrinsic Contrast Ratio (Typ.)	3000:1
Viewing Angle (CR>10)	178°(V) /178°(H)
Display Colors	1.07B (8bit+2FRC)
PBP	Yes
Response Time	4 ms (G To G )
Sound from HDMI	Yes
Earphone	Yes
Speaker	5 W x 2
HDMI input	HDMI2.0 x 2
DisplayPort input	Yes
USB3.0 Port	Upstream x1, Downstream x2 (USB port without power charger when upstream no link)
Power On Consumption	< 47 W* (Measuring a screen brightness of 200 nits without audio/ USB/ Card reader connection)
Power saving mode	< 0.5W
Power off mode	< 0.5W
Voltage Rating	Adapter 20Vdc, 7.5A
Chassis Colors	Black
Tilt	-5° ~ 20°
Temperature (operating)	0°C ~ 40°C

Weight and Dimensions

Phys. Dimension with stand (WxHxD)	1057.12 x 517.46 x 309.03 mm
Phys. Dimension without stand (WxHxD)	1057.12 x 361.26 x 158.66 mm
Box Dimension (WxHxD)	1152 x 456 x 370 mm
Net Weight with Stand (Esti.)	12.0 kg
Net Weight without Stand (Esti.)	8.3kg
Gross Weight (Esti.)	TBD kg
