Asus ROG STRIX XG43VQ User Manual

3-7ASUS LCD Monitor XG Series
5. PBP Setting
The PBP Setting allows you to open up sub-window(s) connected
from any video source.
GameVisual
Color
Input Select
System Setup
MyFavorite
PBP Setting
MOVE/ENTER
BACK
DisplayPort 3840x1080@ 144Hz
Racing Mode
ROG Strix XG43V HDR OFF
PBP Mode
Color setting
PBP Source
EXIT
GamePlus
+
By activating this function, this monitor displays two pictures or three
pictures for any video sources.
• PBP Mode: Select PBPx2 or PBPx3 or turn it off.
• PBP Source: Selects the video input source among,
“HDMI-1”, “HDMI-2” or “DisplayPort”.
• Color setting: Set GameVisual mode for each PBP window.
• To turn on PBP function will disable Adaptive-Sync/FreeSync
and HDR function.
• PBP function is supported below 60Hz.

Asus ROG STRIX XG43VQ Specifications

General

Panel Size	43.4” W (110.23 cm)
Max. Resolution	3840 x 1200
Brightness (Typ.)	450 nits (typical)
Intrinsic Contrast Ratio (Typ.)	3000:1
Viewing Angle (CR>10)	178°(V) /178°(H)
Display Colors	1.07B (8bit+2FRC)
PBP	Yes
Response Time	4 ms (G To G )
Sound from HDMI	Yes
Earphone	Yes
Speaker	5 W x 2
HDMI input	HDMI2.0 x 2
DisplayPort input	Yes
USB3.0 Port	Upstream x1, Downstream x2 (USB port without power charger when upstream no link)
Power On Consumption	< 47 W* (Measuring a screen brightness of 200 nits without audio/ USB/ Card reader connection)
Power saving mode	< 0.5W
Power off mode	< 0.5W
Voltage Rating	Adapter 20Vdc, 7.5A
Chassis Colors	Black
Tilt	-5° ~ 20°
Temperature (operating)	0°C ~ 40°C

Weight and Dimensions

Phys. Dimension with stand (WxHxD)	1057.12 x 517.46 x 309.03 mm
Phys. Dimension without stand (WxHxD)	1057.12 x 361.26 x 158.66 mm
Box Dimension (WxHxD)	1152 x 456 x 370 mm
Net Weight with Stand (Esti.)	12.0 kg
Net Weight without Stand (Esti.)	8.3kg
Gross Weight (Esti.)	TBD kg
