Asus ROG STRIX XG43VQ User Manual

3-15ASUS LCD Monitor XG Series
HDMI
Support Timing table
1 640x480@60Hz
2 640x480@67Hz
3 640x480@72Hz
4 640x480@75Hz
5 720x400@70Hz
6 800x600@56Hz
7 800x600@60Hz
8 800x600@72Hz
9 800x600@75Hz
10 1024x768@60Hz
11 1024x768@70Hz
12 1024x768@75Hz
13 1152x864@75Hz
14 1280x720@60Hz
15 1280x960@60Hz
16 1280x1080@60Hz
17 1280x1024@60Hz
18 1440x900@60Hz
19 1680x1050@60Hz
20 1920x1080@50Hz
21 1920x1080@60Hz
22 2560x1080@60Hz
23 3840x1080@60Hz
24 3840x1080@100Hz
25 3840x1080@120Hz
26 480P@60Hz
27 576P@50Hz
28 720P@50Hz
29 720P@60Hz
30 720P@120Hz
31 1080P@50Hz
32 1080P@60Hz
33 1080P@120Hz
* The modes not listed in the above tables may not be supported. For
optimal resolution, we recommend that you choose a mode listed in
the above tables.

Asus ROG STRIX XG43VQ Specifications

General

Panel Size	43.4” W (110.23 cm)
Max. Resolution	3840 x 1200
Brightness (Typ.)	450 nits (typical)
Intrinsic Contrast Ratio (Typ.)	3000:1
Viewing Angle (CR>10)	178°(V) /178°(H)
Display Colors	1.07B (8bit+2FRC)
PBP	Yes
Response Time	4 ms (G To G )
Sound from HDMI	Yes
Earphone	Yes
Speaker	5 W x 2
HDMI input	HDMI2.0 x 2
DisplayPort input	Yes
USB3.0 Port	Upstream x1, Downstream x2 (USB port without power charger when upstream no link)
Power On Consumption	< 47 W* (Measuring a screen brightness of 200 nits without audio/ USB/ Card reader connection)
Power saving mode	< 0.5W
Power off mode	< 0.5W
Voltage Rating	Adapter 20Vdc, 7.5A
Chassis Colors	Black
Tilt	-5° ~ 20°
Temperature (operating)	0°C ~ 40°C

Weight and Dimensions

Phys. Dimension with stand (WxHxD)	1057.12 x 517.46 x 309.03 mm
Phys. Dimension without stand (WxHxD)	1057.12 x 361.26 x 158.66 mm
Box Dimension (WxHxD)	1152 x 456 x 370 mm
Net Weight with Stand (Esti.)	12.0 kg
Net Weight without Stand (Esti.)	8.3kg
Gross Weight (Esti.)	TBD kg
