ROG STRIX Z590-E GAMING Series
2-3
Chapter 2
2.1.2
Cooling system installation
To install a CPU heatsink and fan assembly
Apply Thermal Interface Material to the
CPU cooling system and CPU before you
install the cooling system, if necessary.
42
44
