2-4 Chapter 2: Setup
2.4 Detachingthearm(forVESAwall
mount)
The detachable arm of this monitor is specially designed for VESA wall mount.
To detach the arm:
1. Have the front of the monitor face down on a table.
2. Remove the covers on where the monitor and the arm meet.
3. Loosen the four screws on the back of the monitor and remove the arm/base.
1 2 3 4
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
• The VESA wall mount kit (100 x 100 mm) is purchased separately.
• Use only the UL Listed Wall Mount Bracket with minimum weight/load
22.7kg (Screw size: M4 x 10 mm)

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Asus ROG SWIFT PG258Q and is the answer not in the manual?

Asus ROG SWIFT PG258Q Specifications

General IconGeneral
3DNo
Panel typeTN
Screen shapeFlat
Display surfaceMatt
Display diagonal24.5 \
Display technologyLED
Native aspect ratio16:9
Viewing angle, vertical160 °
Contrast ratio (typical)1000:1
Display number of colors16.78 million colors
Viewing angle, horizontal170 °
Digital vertical frequency24 - 60 Hz
Digital horizontal frequency30 - 90 kHz
Display brightness (typical)400 cd/m²
Supported graphics resolutions1920 x 1080 (HD 1080)
Dynamic contrast ratio marketing nameMega Contrast
On/off switchYes
Active display area (W x H)0.2832 x 0.2802 mm
Pivot angle0 - 90 °
Tilt angle range-5 - 20 °
Cable lock slot typeKensington
Panel mounting interface100 x 100 mm
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)65 W
Power consumption (standby)- W
Power consumption (PowerSave)0.5 W
USB hub version3.2 Gen 1 (3.1 Gen 1)
VGA (D-Sub) ports quantity0
USB Type-A downstream ports quantity2
Package depth239 mm
Package width661 mm
Package height443 mm
Package weight7900 g
Cables includedAC, DisplayPort, HDMI, USB
CertificationCB, CCC, CE, CEL level 1, CU, ErP, FCC, J-MOSS, KCC, PSE, RoHS, UL/cUL, VCCI, WEEE, WHQL, RCM, TUV, eStandby, TUV
Product colorBlack
Market positioningGaming
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)253.7 mm
Height (with stand)503.7 mm
Weight (with stand)5600 g
Depth (without stand)72.5 mm
Width (without stand)564.1 mm
Height (without stand)330.6 mm
Weight (without stand)3140 g
