Asus RT-AC3100 Quick Start Guide

6
English
3. Set up your wireless environment.
RT-AC3100
Computer
Wall Power Outlet
Modem
Power
LAN
WAN
a
b
c
d
a. Insertyourwirelessrouter’sACadaptertotheDC-INportandplugittoa
power outlet.
b. Usinganothernetworkcable,connectyourmodemtoyourwirelessrouter’s
WAN port.
c. Insertyourmodem’sACadaptertothetheDC-INportandplugittoapower
outlet.
d. Usingthebundlednetworkcable,connectyourcomputertoyourwireless
router’sLANport.EnsurethattheWANandLANLEDsareblinking.
4. Disable some settings on your computer.
a. Disabletheproxyserver,ifenabled.
b. SettheTCP/IPsettingstoautomaticallyobtainanIPaddress.
c. Disable the dial-up connection, if enabled.
NOTE:Formoredetailsondisablingyourcomputersettings,referto
Frequently Asked Questions (FAQs).
E10547_RT-AC3100_QSG.indd 6 6/17/2015 12:55:32 PM

Asus RT-AC3100 Specifications

General

Color	black
Wi-Fi Mesh System	yes
Band Technology	dual
Frequency Band	2.4 ghz, 5.0 ghz
Beamforming	yes
Ethernet Standard	10/100/1000
Ethernet Switch	yes
Wireless Networking Standard	wi-fi 5
Wireless Standard	ac, n
2.4 Ghz Streams	1
5.0 Ghz Streams	1
Gigabit Ethernet Speed	yes
Antennas	4
Parental Control	yes
Firewall	spi
Data Encryption	yes
Encryption Type	wep, wpa2-psk, wpa-psk, wpa-enterprise, wpa2-enterprise
Security Features	64- and 128-bit wep, wpa2-psk, wpa-psk, wpa-enterprise and wpa2-enterprise
Ports	rj-45, usb
LAN Ports	4
WAN Ports	1
Built In Modem	yes
Bluetooth	no
Smart Applications	true, asus router

Weight and Dimensions

Height	7.4 inches
Width	11.81 inches
Net Weight	2 pounds
