A quick look
LED On/O button USB 2.0 port
Wi-Fi On/O button WPS button
Power LED WAN (Internet) port
2.4GHz LED / 5GHz LED LAN 3 ~ 4 ports
LAN 1~4 LED LAN 1 ~ 2 ports (Teaming ports)
WAN (Internet) LED
red: No IP or no physical connection.
on: Has physical connection to a wide
area network (WAN).
Reset button
WPS LED Power button
USB 3.0 port Power (DC-IN) port
LED
WiFi
USB 3.0
