Asus RT-AX3000 User Manual

43
To launch the Media Server setting page, go to General > USB
application > Media Services and Servers > Media Servers tab.
Refer to the following for the descriptions of the elds:
• Enable iTunes Server?: Select ON/OFF to enable/disable the
iTunes Server.
• Media Server Status: Displays the status of the media server.
• Media Server Path Setting: Select All Disks Shared or
Manual Media Server Path.
Using Network Place (Samba) Share service
Network Place (Samba) Share allows you to set up the accounts
and permissions for the Samba service.
To use Samba share:
1. From the navigation panel, go to General > USB application >
Media Services and Servers > Network Place (Samba) Share
/ Cloud Disk tab.
NOTE: Network Place (Samba) Share is enabled by default.

Asus RT-AX3000 Specifications

General

Product type	Tabletop router
LED indicators	LAN, Power, WAN, WLAN
Antennas quantity	4
Output current	2 A
Output voltage	19 V
AC input voltage	110 - 240 V
Power source type	DC
AC input frequency	50 - 60 Hz
Flash memory	256 MB
Internal memory	512 MB
Processor cores	3
Built-in processor	Yes
Processor frequency	1.5 MHz
DSL WAN	No
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	2402 Mbit/s
WLAN data transfer rate (first band)	574 Mbit/s
VPN support	VPN Client L2PT:Yes VPN Client OVPN:Yes VPN Client PPTP:Yes VPN Server IPSec:Yes VPN Server OVPN:Yes VPN Server PPTP:Yes VPN Fusion:No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Cables included	LAN (RJ-45)
MAC address table	64 entries
Security algorithms	WPA, WPA-Enterprise, WPA2, WPA2-Enterprise, WPA3, WPS

Weight and Dimensions

Weight	538 g
