RT-N11 EZ Wireless N Router User Manual
3
R
2. Connecting ADSL Modem and Wireless Router
1. Package Contents
• RT-N11 Wireless Router x 1
• Power Adapter x 1
• Docking Stand x 1
• Utility CD x 1
• RJ-45 cable x 1
1) Cable connection
1
Modem
Wall Telephone Outlet
Wall Power Outlet
Phone
Power
2
Wall Power Outlet
ASUS Wireless Router
LAN
3
Modem
Wall Telephone Outlet
Wall Power Outlet
LAN
Power
Phone
Power
ASUS Wireless Router
WAN
Power
Note:
Use only the adapter included in the package. Using other adapters may
damage the device.
Note: The device in the above illustration is for your reference only. Please refer to
your package for the real product.
Rear Panel
