Asus SABERTOOTH 990FX R2.0 - Front I;O Connector

2-10
Chapter 2: Getting started
Chapter 2
2.1.7 Front I/O Connector
To install ASUS Q-Connector
IDE_LED
POWER SW
RESET SW
IDE_LED-
IDE_LED+
PWR
Reset
Ground
Ground
1
2
USB 2.0
AAFP
To install USB 2.0 connector To install front panel audio connector
USB 3.0
To install USB 3.0 connector
