3-2
Chapter 3: General Instruction
2. Image
This menu allows you to adjust the
image settings.
• Mode: Selects a preset view
option optimized for different
viewing conditions.
• Backlight: Adjusts the
backlight that affects the
overall brilliance of the image.
• Contrast: Adjusts the
difference between the light
and dark levels in the image.
• Brightness: Adjusts the
brightness setting.
• Color: Adjusts the color
intensity of the image.
• Hue: Adjusts the image hue.
• Sharpness: Adjusts the sharpness of the edges of elements in
the image.
• Color Temp.: Configures the color settings.
• Color Temp.: Applies a preset color temperature setting.
• Red Gain/Green Gain/Blue Gain: Adjusts the red/green/
blue gain settings to your preference.
• Red Offset/Green Offset/Blue Offset: Adjusts the red/
green/blue offset settings to your preference.
Red Gain/Green Gain/Blue Gain/Red Offset/Green
Offset/Blue Offset option is only available if the
Color Temp. setting is set to User Mode .
• Advanced Setting: Configures the advanced Image settings.
• Crystal Color
TM
: Produces more vivid and crisp color
image.
• Dynamic Contrast: Adjusts the screen contrast to
maximize the image quality.
• Adaptive Backlight: Enables or disables the display to
automatically adjust the screen brightness according to the
ambient lighting.
• Reset: Resets all Image settings to the factory default settings.
Mode
Backlight
Contrast
Brightness
Color
Hue
Sharpness
Color Temp.
Advanced Seng
Reset
Standard Mode
80
50
50
65
0
8
Sound
System Setup
Aspect
Schedule
Input Select
