The OSD (On-Screen Display) menu42
Aspect
(continued)
• Full: Enlarges the picture horizontally to fill the screen when the picture
source is 4:3 (Standard definition). When the picture source is 16:9 (High
definition), it displays in the same 16:9 aspect ratio.
• 4:3: Displays all picture source in 4:3 aspect ratio.
• Full 1: Enlarges the picture to fill the screen in the vertical direction,
keeping the same aspect ratio. A black frame may appear around the
picture.
• Full 2: Enlarges the picture to fill the screen.
• Real: Displays the picture in its original number of dots.
Adjust Screen
• Auto Adjustment: Sets whether to optimize image display for VGA input.
• Phase: Adjusts the phase of the VGA input image.
• Clock Frequency: Adjusts the clock frequency of the VGA input image.
• H. Position: Adjusts the horizontal position of the VGA input image.
• V. Position: Adjusts the vertical position of the VGA input image.
Freeze Freezes the displayed image.
