Asus VE247H - Assembling the Monitor Base

2-1ASUSVE247/VE248/VE249SeriesLEDMonitor
2.1 Assembling the monitor base
To assemble the monitor base:
1. Have the front of the monitor face down on a table.
2. Assemblethebaseandthearmbyaligningthearrowmarksonthebaseand
the arm.
3. Fixthebasetothearmbyfasteningthebundledscrew.
Werecommendthatyoucoverthetablesurfacewithsoftclothtoprevent
damage to the monitor.
1
Re lea se L oc k
2
2.2 Adjusting the monitor
• Foroptimalviewing,werecommendthatyoulookatthefullfaceofthe
monitor,thenadjustthemonitortotheanglethatismostcomfortableforyou.
• Holdthestandtopreventthemonitorfromfallingwhenyouchangeitsangle.
• Therecommendedadjustinganglefrom-5˚to20˚.
-5˚~20˚
Itisnormalthatthemonitorslightlyshakeswhileyouadjustthetheviewing
angle.
