Asus VE247H - Detaching the Arm;Base (for VESA Wall Mount)

2-2-2 Chapter 2: Setup
2.3 Detaching the arm/base
(for VESA wall mount)
Thedetachablearm/baseofthisLEDmonitorisspeciallydesignedforVESAwall
mount.
Todetachthearm/base:
1. Have the front of the monitor face down on a table.
2. Removetherubbersinthefourscrewholes(Figure1).
3. Useascrewdrivertoremovethetwoscrewsonthearm(Figure2),thenslide
outthearm/basetodetachitfromthemonitor(Figure2).
1
Rel ease Lo ck
Arm/base
Rubbers in the
screw holes
Figure 1 Figure 2
2
1
Rele ase Loc k
We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
