Asus VG35VQ User Manual

3-7
ASUS LCD Monitor VG35V Series
• PIP/PBP will be disabled if main or sub-source is Adaptive-Sync enabled.
Change those sources to non Adaptive-Sync to enable PIP/PBP function.
• PIP/PBP function is disabled when main or sub source is HDR video.
• Turn off PIP/PBP mode automatically when main or sub source is HDR video.
• PIP/PBP will be disable when monitor is resume to operating from power
saving.
6. Input Select
Select the input source from HDMI-1, HDMI-2 or DisplayPort input
signal.
Input Select
HDMI-1
DisplayPort
HDMI-2
Racing Mode DisplayPort 1920x1080@60Hz
ASUS TUF Gaming VG35V HDR OFF
7. System Setup
Adjuststhesystemconguration.
Key Lock
System Setup
GameVisual Demo Mode
ECO Mode
USB Charging
OSD Setup
Sound
Language
More
Racing Mode DisplayPort 1920x1080@60Hz
ASUS TUF Gaming VG35V HDR OFF

Asus VG35VQ Specifications

General

Panel Size	35”W (88.9cm)
Max. Resolution	3440x1440@100Hz
Brightness (Typ.)	300cd/m2
Intrinsic Contrast Ratio (Typ.)	2500:1
Viewing Angle (CR=10)	178°(V) /178°(H)
Display Colors	16.7 M
Response Time	4ms (Gray to Gray) 1ms MPRT
Earphone Output	Yes
Sound from HDMI	Yes
HDMI input	Yes
DisplayPort input	Yes
Power ON Consumption(Max.)	< 45 W* (Measuring a screen brightness of 200 nits without audio/ USB/ Card reader connection)
Power saving mode	< 0.5W
Power off mode	< 0.5W
Voltage Rating	AC 100~240V(Built-in)
Chassis Colors	Black
Tilt	-5° ~ +20°
Temperature (operating)	0°C ~ 40°C

Weight and Dimensions

Phys. Dimension (WxHxD)	834.6 x 561.1 x 231.6 mm
Phys. Dimension without stand (WxHxD)	834.6 x 381.4 x 122.9 mm
Box Dimension (WxHxD)	930 x 659 x 282 mm
Net Weight (Esti.)	12 kg
Gross Weight (Esti.)	17.2 kg
