Asus Xonar U3 User Manual

20 ASUS Xonar U3
8.4.2 10-Band Equalizer
The equalizer can modify the audio output for different frequencies, and be used
to compensate for deciencies in your speakers/systems. There are 12 default
patterns and you can also make your own settings.
No Item Description
1 Default equalizer
options
There are 12 available equalizer patterns. Click one to apply
it.
2 UserDened
You can click this button to apply your own dened
parameters saved in the pull-down menu.
3 Equalier slider
Adjust the gain for each band (30~16KHz).
4 Save name
Key in a name for your own “User Dened” equalizer setting.
5 Add / save
Click this “+” button to save the parameters into User Dened
list.
6 Delete
Click this “–” button to delete the parameters from User
Dened list.
1 3
2 4 5 6

Asus Xonar U3 Specifications

General

Internal	No
Audio quality	16 bit
Audio output channels	2.0 channels
Line-out Signal-to-Noise Ratio (SNR)	105 dB
Line-out Total Harmonic Distortion (THD)	0.005 %
Headphone outputs	2
LED indicators	Yes
Dolby technologies	Dolby Digital Live, Dolby Headphone, Dolby Pro-Logic IIx, Dolby Virtual Speaker
Audio system maximum sampling rate	48 kHz

Weight and Dimensions

Depth	79.5 mm
Width	30.6 mm
