ASUS Z87-A
1-36
6. USB 2.0 connectors (10-1 pin USB910; USB1112; USB1314)
These connectors are for USB 2.0 ports. Connect the USB module cable to any of
these connectors, then install the module to a slot opening at the back of the system

480 Mbps connection speed.

then install the Q-Connector (USB) to the USB connector onboard if your chassis supports
front panel USB ports.
Never connect a 1394 cable to the USB connectors. Doing so will damage the
motherboard!
• The USB 2.0 module is purchased separately.
 
related driver to fully use the USB 2.0 ports under Windows
®
7.
