Asus Z9PE-D16 User Manual

ASUS Z9PE-D16 Series 4-17
Memory Conguration
Support for compatibility
Revision ID(CRID)
Functionality mentioned in
Sandybridge bios spec.
Compatibility RID [Enabled]
Memory Conguration
Total Memory 2048 MB (DDR3)
Current Memory Mode Independent
Currently Memory Speed 1333 MHz
Mirroring Supported
Sparing Not Possible
Memory Mode [Independent]
DDR Speed [Auto]
Channel Interleaving [Auto]
Rank Interleaving [Auto]
Patrol Scrub [Disabled]
Demand Scrub [Enabled]
Data Scrambling [Enabled]
Device Tagging [Disabled]
Thermal Throtting [CLTT]
OLTT Peak BW  50OLTT Peak BW  50
Enable High Temp [Disabled]
Allow 2x Refresh [Enabled]
Altitude [300 M]
Memory HOT Sensor support [Enabled]
DIMM Information
Compatibility RID [Enabled]
Support for compatibility revision ID (CRID) functionality mentioned in Sandybridge
BIOS spec. Conguration options: [Enabled] [Disabled]
Memory Mode [Independent]
Select the mode for memory initializaton.
Conguration options: [Independent] [Mirroring] [Lock Step] [Sparing]
DDR Speed [Auto]
Force DDR speed.
Conguration options: [Auto] [Force DDR3 800] [Force DDR3 1066] [Force DDR3
1333] [Force DDR3 1600] [Force DDR3 1866]
Channel Interleaving [Auto]
Select different channel interleaving setting.
Conguration options: [Auto] [1 Way] [2 Way] [3 Way] [4 Way]
Rank Interleaving [Auto]
Select different rank interleaving setting.
Conguration options: [Auto] [1 Way] [2 Way] [4 Way] [8 Way]
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Advanced
Version 2.15.1219. Copyright (C) 2011 American Megatrends, Inc.

Asus Z9PE-D16 Specifications

General

Microphone in	No
Serial ports quantity	0
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 2.0 connectors	3
Chassis intrusion connector	Yes
PCI Express x16 slots	6
PCI Express slots version	3.0
PCI Express configurations	1x16
Memory channels	Quad-channel
Maximum RDIMM memory	512 GB
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	1066, 1333, 1600 MHz
Number of DIMM slots	16
Supported RDIMM module capacity	16GB, 2GB, 4GB, 8GB
Supported UDIMM module capacity	2GB, 4GB, 8GB
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA, SATA II, SATA III
On-board graphics card model	Aspeed AST2300
On-board graphics card memory	16 MB
Parallel processing technology support	Not supported
Certification	US (FCC, CFR47 15 A), Europe (CE, EN55022 / EN55024), Australia (C-TICK)
Motherboard chipset	Intel® C602
Cables included	SATA, USB
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 90 %
Supported QPI	6.4, 7.2 GT/s
Processor socket	LGA 2011 (Socket R)
Processor manufacturer	Intel
Processor number of cores supported	4, 8
Ethernet interface type	Gigabit Ethernet

Weight and Dimensions

Depth	330 mm
Width	305 mm
