ASUSTeK COMPUTER COK-002 User Manual

4-1
Reproduction Prohibited
SC
Ref. No. Part No. Description
Remark SC
Ref. No. Part No. Description
Remark
SECTION 4
ELECTRICAL PARTS LIST
NOTE:
•
Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
•
RESISTORS
METAL:Metal-film resistor.
F:nonflammable
•
SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
•
CAPACITORS
uF : µF
•
COILS
uH : µH
S
A-1267-250-A BL1-001 COMPL (SERVICE)
******************************************************************
U
BL2-001 COMPL
******************************************************************
S
A-1267-249-A BMD-001 COMPL (SERVICE)
SC
Ref. No. Part No. Description
Remark SC
Ref. No. Part No. Description
Remark
When indicating parts by reference
n
umber, please include the board.
NOTE:
• SC Classification:
S : Supplied parts
U : Unsupplied parts
The components identified by
mark
or dotted line with mark
are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
SPECIAL COMPONENT NOTICE
The components identified by mark contain
confidential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
CECHC02, C03, C04, C08
Manufactured by ASUSTek
CECHE01, E05, E11
!
!
!
S
A-1226-214-A CMC-001 COMPL (SERVICE)
!
******************************************************************
S A-1257-553-A COK-002 COMPL (HC) (SERVICE)
***************************
< BUZZER >
S BZ4001 1-529-986-11 BUZZER, VOLTAGE
< CAPACITOR >
S C1101 1-114-248-91 TANTAL. CHIP 330uF 20% 2.5V
S C1102 1-114-248-91 TANTAL. CHIP 330uF 20% 2.5V
S C1105 1-114-248-91 TANTAL. CHIP 330uF 20% 2.5V
!
******************************************************************
S
C2267 1-114-248-91 TANTAL. CHIP 330uF 20% 2.5V
S
C2453 1-126-210-21 ELECT CHIP 220uF 20% 4V
S
C2454 1-100-815-21 ELECT CHIP 1000uF 20% 4V
S
C2455 1-126-210-21 ELECT CHIP 220uF 20% 4V
S
C5031 1-100-425-91 TANTAL. CHIP 220uF 20% 10V
S C6028 1-114-253-21 TANTAL. CHIP 330uF 20% 6.3V
S C6029 1-114-253-21 TANTAL. CHIP 330uF 20% 6.3V
S
C6095 1-112-561-21 TANTAL. CHIP 220uF 20% 2.5V
S
C6116 1-112-861-11 ELECT CHIP 150uF 20% 16V
S
C6117 1-112-861-11 ELECT CHIP 150uF 20% 16V
S
C6118 1-112-861-11 ELECT CHIP 150uF 20% 16V
S
C6140 1-114-167-11 ELECT 1200uF 2.5V
S
C6141 1-114-167-11 ELECT 1200uF 2.5V
S
C6142 1-114-167-11 ELECT 1200uF 2.5V
S
C6143 1-114-167-11 ELECT 1200uF 2.5V
S
C6212 1-112-561-21 TANTAL. CHIP 220uF 20% 2.5V
S
C6217 1-114-250-21 ELECT CHIP 150uF 20% 16V
S
C6218 1-114-250-21 ELECT CHIP 150uF 20% 16V
S
C6229 1-114-167-11 ELECT 1200uF 2.5V
S
C6230 1-114-167-11 ELECT 1200uF 2.5V
S
C6231 1-114-167-11 ELECT 1200uF 2.5V
S
C6232 1-114-167-11 ELECT 1200uF 2.5V
S
C6336 1-114-251-21 TANTAL. CHIP 470uF 20% 2.5V
S C6341 1-114-251-21 TANTAL. CHIP 470uF 20% 2.5V
S
C6342 1-114-251-21 TANTAL. CHIP 470uF 20% 2.5V
S
C6343 1-114-251-21 TANTAL. CHIP 470uF 20% 2.5V
S C6344 1-114-251-21 TANTAL. CHIP 470uF 20% 2.5V
S
C6369 1-112-561-21 TANTAL. CHIP 220uF 20% 2.5V
S
C6370 1-112-561-21 TANTAL. CHIP 220uF 20% 2.5V
S
C6371 1-112-561-21 TANTAL. CHIP 220uF 20% 2.5V
S
C6620 1-112-561-21 TANTAL. CHIP 220uF 20% 2.5V
S
C8051 1-114-248-91 TANTAL. CHIP 330uF 20% 2.5V
S
C8080 1-100-425-91 TANTAL. CHIP 220uF 20% 10V
< CONNECTOR >
S
CN2401 1-820-793-11 CONNECTOR, SQUARE TYPE 12P
S
CN2501 1-820-794-13 CONNECTOR, HDMI 20P
S
CN3209 1-778-063-11 PIN, CONNECTOR (PC BOARD) 4P
S
CN3219 1-820-657-11 CONNECTOR, FFC/FPC (ZIF) 15P
S
CN3221 1-820-750-71 FFC/FPC CONNNECTOR (ZIF) 60P
S
CN3301 1-820-671-12 CONNECTOR, USB (SOCKET) 8P
S
CN3302 1-820-671-12 CONNECTOR, USB (SOCKET) 8P
S
CN3401 1-820-654-11 CONNECTOR, SATA 22P
S
CN3501 1-820-763-12 JACK, MODULAR (WITH LED, PT)
S
CN3701 1-820-786-11 CONNECTOR, FFC/FPC (ZIF) 33P
S
CN4001 1-794-509-21 PIN, CONNECTOR (PC BOARD) 3P
S
CN4003 1-820-789-11 PIN, CONNECTOR (PC BOARD) 2P
S
CN4010 1-820-825-61 CONNECTOR, FFC/FPC 10P
S
CN6004 1-820-723-11 CONNECTOR, BOARD TO BOARD 2P
S
CN6005 1-778-315-11 PIN, CONNECTOR (PC BOARD) 5P
< TERMINAL >
S
ET8001 1-780-465-11 TERMINAL (ON BOARD CONTACT)
S
ET8002 1-780-465-11 TERMINAL (ON BOARD CONTACT)
< FUSE >
S
F6001 1-576-679-11 FUSE, CHIP (3216) (5A/32V)
S
F6301 1-576-679-11 FUSE, CHIP (3216) (5A/32V)
S
F6302 1-576-679-11 FUSE, CHIP (3216) (5A/32V)
S
F6303 1-576-679-11 FUSE, CHIP (3216) (5A/32V)
S
F6304 1-576-679-11 FUSE, CHIP (3216) (5A/32V)
!
!
!
!
!
< IC >
S IC1001 8-753-283-22 IC CXD2964AGB
S IC1101 6-710-287-01 IC AD51/067ARMZ-REEL
S IC1201 6-710-256-01 IC EDX5116ACSE-3C-E
S IC1202 6-710-256-01 IC EDX5116ACSE-3C-E
S IC1301 6-710-256-01 IC EDX5116ACSE-3C-E
S IC1302 6-710-256-01 IC EDX5116ACSE-3C-E
S IC2001 8-753-251-46 IC CXD2971GB
S IC2101 6-710-286-01 IC ADT7461A0002RMZR
S
IC2102 6-710-158-01 IC ICS422AG-07LFT
S IC2103 6-710-430-01 IC ICS651MLFT
S IC2108 6-710-430-01 IC ICS651MLFT
S IC2200 6-711-085-01 IC ICS628G-01LFT
S IC2402 6-702-257-01 IC MC78M09CDTRKG
S IC2405 6-710-230-01 IC CX4351-CZZR
S
IC2406 8-753-248-24 IC CXM4024R-T6
S IC2407 6-709-980-01 IC MM1593DFBEG
S IC2408 6-700-227-01 IC MM1561JFBE
S
IC2409 1-479-960-11 TRANSMITTER UNIT, LIGHT
S
IC6004 6-710-166-01 IC PST3642UL
S
IC6005 6-710-217-01 IC NCP511SN33T1G
S
IC6006 6-703-212-01 IC NCP511SN18T1
S
IC6007 6-710-210-01 IC TPS73101DBVRG4
S
IC6008 6-703-212-01 IC NCP511SN18T1
S
IC6009 6-710-217-01 IC NCP511SN33T1G
S
IC6011 6-710-216-01 IC NCP511SN25T1G
S
IC6012 6-709-932-01 IC MM3141CNRE
S
IC6013 6-710-215-01 IC MM1562ZFBE
S
IC6014 6-704-531-01 IC MM1591JFBEG
S
IC6017 6-710-214-01 IC BD3521FVM-TR
S
IC6019 6-703-629-01 IC NCP511SN15T1G
S
IC6020 6-709-980-01 IC MM1593DFBEG
S
IC6023 6-710-166-01 IC PST3642UL
S
IC6103 6-710-177-01 IC NCP5318FTR2G
S
IC6104 6-710-178-01 IC IP2003ATRPBF
S
IC6105 6-710-178-01 IC IP2003ATRPBF
S
IC6106 6-710-178-01 IC IP2003ATRPBF
S
IC6107 6-710-250-01 IC TC7SG08FU
S
IC6200 6-710-212-01 IC BD3520FVM-TR
S
IC6201 6-710-177-01 IC NCP5318FTR2G
S
IC6202 6-710-178-01 IC IP2003ATRPBF
S
IC6203 6-710-178-01 IC IP2003ATRPBF
S
IC6204 6-710-250-01 IC TC7SG08FU
S
IC6301 6-703-249-01 IC SN105233DBTR
S
IC6302 6-710-197-01 IC TPS51117PWRG4
S
IC6303 6-710-212-01 IC BD3520FVM-TR
S
IC6304 6-710-211-01 IC BD3504FVM-TR
S
IC6305 6-710-212-01 IC BD3520FVM-TR
S
IC6601 6-710-216-01 IC NCP511SN25T1G
S
IC6602 6-710-211-01 IC BD3504FVM-TR
S
IC6603 6-710-217-01 IC NCP511SN33T1G
S
IC8001 8-753-256-69 IC CXD2972GB-T7
< IC LINK >
S
PS3501 1-576-282-21 LINK, SQUARE CHIP TYPE IC (1.2A/72V)
S
PS6001 1-533-282-21 LINK, IC (2A/72V)
!
!
S IC3101 6-710-196-01 IC AD51/007Z-0REEL
S
IC3302 6-806-870-01 IC BU9869W-02-TR
S IC3303 6-707-066-01 IC BD6517F
S
IC3304 6-707-066-01 IC BD6517F
S IC3305 6-806-862-01 IC GL852-MSG02-MT
S
IC3401 6-710-129-01 IC 88SA8040C0-TBC1C000-P107
S
IC3501 6-710-212-01 IC BD3520FVM-TR
S
IC3502 6-710-206-01 IC MM1761KHBE
S
IC3503 6-710-202-01 IC 88E6108-B2-LAR1C000-P123
S
IC3801 8-753-265-45 IC CXD4302GB-T6
S
IC3804 6-711-066-01 IC TC7SZ07FU(T5RSONYF
S
IC5001 6-710-156-01 IC ICS1493G-18LFT
S
IC5002 6-710-157-01 IC ICS9218AGLFT
S
IC5003 6-710-157-01 IC ICS9218AGLFT
S
IC5004 6-710-154-01 IC ICS9214DGLFT
S
IC5005 6-701-979-01 IC TC7WB66FK(TE85R)
S
IC6003 6-705-646-01 IC MB39A116PFT
S
C2458 1-100-815-21 ELECT CHIP 1000uF 20% 4V
S
C2469 1-128-995-21 ELECT CHIP 100uF 20% 10V
S
C3002 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V
S
C3006 1-128-964-91 TANTAL. CHIP 100uF 20% 6.3V
S C3009 1-114-248-91 TANTAL. CHIP 330uF 20% 2.5V
S
C3013 1-128-964-91 TANTAL. CHIP 100uF 20% 6.3V
S
C3215 1-137-689-91 TANTAL. CHIP 47uF 20% 16V
S
C3246 1-137-934-91 TANTAL. CHIP 47uF 20% 10V
S
C3247 1-100-388-21 ELECT CHIP 39uF 20% 16V
S
C3322 1-100-425-91 TANTAL. CHIP 220uF 20% 10V
S
C3323 1-100-425-91 TANTAL. CHIP 220uF 20% 10V
S
C3324 1-100-425-91 TANTAL. CHIP 220uF 20% 10V
S
C3325 1-100-425-91 TANTAL. CHIP 220uF 20% 10V
S
C3401 1-137-934-91 TANTAL. CHIP 47uF 20% 10V
S
C3544 1-112-561-21 TANTAL. CHIP 220uF 20% 2.5V
S
C1501 1-114-248-91 TANTAL. CHIP 330uF 20% 2.5V
S
C1503 1-114-248-91 TANTAL. CHIP 330uF 20% 2.5V
S
C1601 1-114-248-91 TANTAL. CHIP 330uF 20% 2.5V
S
C1603 1-114-248-91 TANTAL. CHIP 330uF 20% 2.5V
S
C2121 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V
S
C2124 1-100-539-91 TANTAL. CHIP 47uF 20% 6.3V
S
C2133 1-114-251-21 TANTAL. CHIP 470uF 20% 2.5V
S
C2457 1-100-815-21 ELECT CHIP 1000uF 20% 4V
S IC2501 6-710-429-01 IC TC7WP3125FK(T5RSOF
S IC3002 8-753-273-22 IC CXD2979GB
