Pro B460M-C specifications summary
Storage
Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports
Intel
®
B460 Chipset
M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA
modes)*
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 mode)**
6 x SATA 6Gb/s ports
Intel
®
Rapid Storage Technology supports Raid 0,1,5,10
Intel
®
Optane™ Memory Ready
* When a device in SATA mode is installed on the M.2_1 socket, SATA6G_1 port
cannot be used.
** Only M.2_2 supports IRST.
Ethernet
1 x Intel
®
I219V 1Gb Ethernet
ASUS LANGuard
USB
Rear USB (Total 6 ports)
4 x USB 3.2 Gen 1 ports (4 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
Front USB (Total 6 ports)
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
2 x USB 2.0 headers support additional 4 USB 2.0 ports
Audio
Realtek ALC887 7.1-Channel High Denition Audio CODEC*
- Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Supports up to 24-Bit/192kHz playback
*AchassiswithanHDaudiomoduleinthefrontpanelisrequiredtosupport
7.1-channel audio output.
Back Panel I/O Ports
4 x USB 3.2 Gen 1 ports (4 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
2 x DisplayPorts
1 x D-sub port
1 x HDMI
TM
port
1 x Intel
®
I219V 1Gb Ethernet port
3 x Audio jacks
1 x PS/2 keyboard (purple) port
1 x PS/2 mouse (green) port
Internal I/O
Connectors
Fan and cooling related
1 x 4-pin CPU Fan header
2 x 4-pin Chassis Fan headers
Power related
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
Storage related
2 x M.2 slots (Key M)
6 x SATA 6Gb/s ports
USB
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
2 x USB 2.0 headers support additional 4 USB 2.0 ports
(continued on the next page)
