Asyril Asycube 530 Integration Guidelines

Asycube mechanical integration guidelines
000.103.437
Version : A
4/14
Acronyms
APSO
Angst + Pfister - www.apsoparts.com – (section: Antivibration Technology; APSOvib)
A
max. support length for Asycube
B
max. support width for Asycube
c
distance between Asycube(s)
ØD
diameter of the round buffer APSOvib
H
height of the round buffer APSOvib
c
z
spring constant of the round buffer APSOvib; compression in Z direction (axial direction)
F
z
max. allowed compressive force of the round buffer APSOvib
M
mass (used for Asycube feature definition)
N/A
not applicable
Qty.
quantity
Ref.
reference
