EN 15
INSTALLATION AND CONNECTION
min. 20
min. 50
50
460
598
595
560
572
545
21
90°
min. 550
min. 560
min. 600
High Cabinet
min. 550
min. 560
min. 590 ~ max. 600
50
Low Cabinet
Safety instructions for the installation
This oven may be installed only by an approved electrician. The
installer is responsible for connecting the appliance to the mains and in
so doing for observing the relevant safety regulations.
• Ensure protection from live parts when installing the oven.
• The kitchen cabinet in which the oven is built in must satisfy
stability requirements as specified in DIN 68930.
Installation in the cabinet
This is a built-in oven, which needs to be installed into an upper or
lower cabinet.
• Observe the minimum distances.
• The oven should be slid into place at the proper angle of alignment.
