Step 3 - Connect Router to T1 Access Circuit(s)
Connect your T1 circuit(s) using the Grey T1 cable(s) to the port(s) labeled
Port 1-4.
7
T1 Cable(s) labelled ISE642
To smart jack(s)
Note: Up to 4 T1’s may be utilized. If using a single T1 then plug the T1 cable into port 1.
A second T1 should be plugged into port 2, third into port 3 and fourth into port 4.
