7
Wall-mount installation (optional)
Plug the telephone line into
the telephone base. Route
the telephone line cord (or
DSL filter) through the wall-
mount bracket hole.
Plug the telephone line cord
(or DSL filter) into the wall jack.
Plug the power adapter into a
power outlet not controlled by
a wall switch.
Align the holes on the wall-mount
bracket with the standard wall
plate and slide the wall-mount
bracket down until it locks
securely. Bundle the telephone
line cord and power adapter cord
neatly with twist ties.
3 4
Position the telephone base, as
shown below. Insert the extended
tabs (marked B in the following
illustration) of the wall-mount
bracket into the slots on the back
of the telephone base. Push the
telephone base down until it is
securely in place.
