Table 8: Torques and current intensities for live pins
Thread size
Torque [Nm]
Permissible continuous current [A]
Brass Copper
M4
1.2 16 -
M5 2 25 -
M6 3 63 -
M8 6 100 -
M10 10 160 200
M12 15.5 250 315
M16 30 315 400
M20 52 400 630
Depending on the model, additional terminals for instance for temperature
monitoring or space heater are located either in the main terminal box or in
additional terminal boxes; see the supplied wiring diagram.
Please note!
Take note of the rating data imprinted on the terminals.
Please note!
Keep the wiring diagram supplied in the terminal box in the
enclosure with the documents belonging to the drive.
