ATD Tools ATD-8116F - Parts and Hardware

10mm
1/2Ó x 10mm Bolt x4
18mm
19mm
19mm
14mm
14mm Bolt
A1 - Front Caster x 2
(ATD-10238R)
A2 - Locking Caster x 2
(ATD-10237)
B - 18mm Flange Nut x 4
C - 19mm Lock Nut x 4
D - 8mm Lock Nut x 8 8
E - 10mm Lock Nut x 6
F - 2.5” x 19mm Bolt x 4
G1 - 3” x 14mm Bolt x 2
G2 - 9/16” x 14mm Bolt x 6
G3 - 1/2” x 10mm Bolt x4
H - 5/8” x 6mm Phillips Screw x 4
I - Pin x 2
J - Square Tube
M1 - Right Leg
M2 - Left Leg
K - Base
O - Step Section
N - Angle Adjustment Keeper x 2
L - Chest Pad Frame
P - Chest Pad
(910993)
S - Pouch Bracket
R - Pouch
U - Bumper Pad x 3
Q - Washer x 2
Parts And Hardware
