By selecting the input type, the way the device counts with the signals from the input channels is selected.
There are 9 different counting options. How they work is described below.
In order to select counter type, pressed to prg button at operation mode. Found to Cnt_typ menu with up-
down button and pressed to prg button then bottom row choice flashes. Make the selection with up-down
button and saved value by prg button. Then return with rst button to operating mode.
Indicates the rotational speed in RPM (rev/
min).
Increases with A and B signals.
Decreases with A signal, increases with B signal.
Decreases with A and B signals.
Increases with A signal,
A counts down as long as signal B is received.
Decreases with A signal,
A counts forward as long as signal B is received.
Increases with A signal,
As long as signal B is received, signal A is not
counted.
Decreases with A signal,
As long as signal B is received, signal A is not
counted.
Provides accurate display of sensors with different resolutions by entering the multiplier value.
By way of example, 0,025 constant value is entered to Const Menu for the 25 micron-sensor or 0,005
constant value for 5 micron-sensor. So when sensor moves 100mm, value of 100 is displayed on the
screen.
In order to set to Conts Menu, pressed to prg button while operating mode and ound to Const Menu with
using up-down button. When pressed to prg button (While being cons menu), the right-hand digit of
