Multiline commands: Command Description
take auto inc: {true/false} slate take auto increment
good take: {true/false} slate good take
environment: {interior/exterior} slate environment
day night: {day/night} slate day or night
slate project:↵ set slate project information:
project name: {name} project name (can be empty, supports UTF-8)
camera: {index} set camera index e.g. A
director: {name} director (can be empty, supports UTF-8)
camera operator: {name} camera operator (can be empty, supports UTF-8)
slate lens:↵ set lens information:
lens type: {type} lens type (can be empty, supports UTF-8)
iris: {type} camera iris (can be empty, supports UTF-8)
focal length: {length} focal length (can be empty, supports UTF-8)
distance: {distance} lens distance (can be empty, supports UTF-8)
filter: {filter} lens filter (can be empty, supports UTF-8)
Command Combinations
You can combine the parameters into a single command, for example:
play: speed: 200 loop: true single clip: true
Or for configuration:
configuration: video input: SDI audio input: XLR
Or to switch to the second disk, but only play NTSC clips:
slot select: slot id: 2 video format: NTSC
Protocol Details
Connection
The HyperDeck Ethernet server listens on TCP port 9993.
Basic syntax
The HyperDeck protocol is a line oriented text protocol. Lines from the server will be separated by an ascii
CR LF sequence. Messages from the client may be separated by LF or CR LF.
New lines are represented in this document as a "↵" symbol.
Single line command syntax
Command parameters are usually optional. A command with no parameters is terminated with a new line:
{Command name}↵
If parameters are specified, the command name is followed by a colon, then pairs of parameter names and
values. Each parameter name is terminated with a colon character:
{Command name}: {Parameter}: {Value} {Parameter}: {Value} ...↵
