2 In the transition control block, press the CUT button. The sources selected on the program
and preview buses are exchanged to indicate that the video source that was on preview is
now on program and vice versa.
TIP It’s recommended to use the transition control block to perform transitions
because it provides the opportunity to verify the video content on the preview output
before sending it to the program output, for example to verify that a camera is in focus.
Press the button marked CUT in the transition control block to perform a cut transition
Auto Transitions
An auto transition allows you to automatically transition between program and preview sources
at a predetermined rate. Any upstream keys that were selected in the next transition and any
downstream keys that were tied to the transition control will also change state. Auto transitions
are performed using the auto button in the transition control block. Mix, dip, wipe, DVE and
stinger transitions can all be performed as an AUTO transition.
Transition types, for example dip, mix and wipe,
have their own independent selection button.
To perform an auto transition
1 On the preview bus, select the video source that you want on the program output.
2 Select the transition type using the transition type buttons in the transition control block.
3 On the LCD menu use the control knobs to set the transition rate and adjust any other
parameter for the transition as needed.
4 Press the AUTO button in the transition control block to initiate the transition.
During the transition, the red and green buttons on the program and preview buses both
turn red to indicate that you are in the middle of a transition. The fader bar or transition slider
76Performing Transitions using ATEM Hardware Panels
