VB100 User Manual
10
Specifications
Function VB100
Connectors Video In 1 x HDB-15 Female (Blue)
Video Out 1 x HDB-15 Female (Blue)
Power Jack 1 x DC Jack
Switches Manual Gain Control 1 x knob
LED Power 1 (Green)
Video Signal Range 1920x1200@60Hz at 30m,
1280x1024@60Hz at 70m
Power Consumption DC 5V; 0.9W
Environment Operating Temp. 0–50ºC
Storage Temp -20–60ºC
Humidity 0–80% RH, Non-condensing
Physical
Properties
Housing Metal
Weight 56 g
Dimensions
(L x W x H)
6.88 x 3.53 x 2.06 cm
