atersa leo 1 - REGULATION SYSTEM MODIFICATION

Restore Factory Values
Accumulators Capacity Updating:
Regulation System Modification:
If after having made some modification, you want to record again the values programmed in
factory, you will have to:
1.Push simultaneously . Many figures will appear by sequences on the display
and will stop when 'Fin' appear on it.
The equipment will make an optimum regulation if you programme the accumulators
approximate capacity. This way, the calculation algorithms will know at each moment what
is the Cx with which the system is working. The minimum programmable capacity is 50 Ah
and the maximum is 950 Ah for the 15A and 25A models. For the model
1.Push simultaneously until the actual capacity of the battery appears
2.Push to reduce or to increase.
3.Push to accept or record.
You can select two types of regulation in accordance with the kind of battery. By defect, the
equipment leaves the factory with the regulation in PbAMode.
Make the charge of the battery in two phases, deep charge and floating. It is the advised
mode for Lead-Acid batteries (liquid electrolyte). It is also convenient to use it for big sized
Gel batteries (gel electrolyte). For it:
1.Push simultaneously until 'ALL' appears on the display.
2.Push simultaneously until the message 'PbA' appears on the display.
Does not make deep charges. Only floating. Usually, small or medium Gel batteries are
used (gel electrolyte), or systems that are not used to being in floating (phone posts SOS,
security systems, etc.). For it:
1.Push simultaneously until 'ALL' on the display.
2.Push simultaneously until the message 'FLO' appears on the display.
q
q
q
Programming sequence:
Mode PbA:
Mode FLO:
LEO1 30A the
minimum programablecapacity is 200Ah and the maximum is 24000Ah.
On the display we see in x1000Ah, for example:
ü
ü
200Ah will be shown on the display as 0.2
24000Ah will be shown on the display as 24.0
+
A
V
A
A
V
+
V
A
+ +
A
V
A
+ +
A
V
A
+
AA
+
A
V
DIGITAL CHARGEREGULATOR LEO1
12
MU-12-L
