atersa leo 1 - Manual Data Acquisition

MANUALDATAACQUISITION
By pushing simultaneously we make a test of components and obtain by
sequence a listing of some parameters as follows:
Remarks: The boards of programmed and handling voltages, you will observe that they
always refer to a 12 v. accumulator, independently from operation voltage of 12,24 or 48v.
Then the real value is multiplied by 1 (12v), by 2 (24v) or by 4 ( 48v).
+
AA
Nº Description Value
1 Led nº1 (Deep charge Phase) lit.
2 Led nº2 (Floating Phase) lit.
3 Led nº3 (Consumption unplugging for low voltage) lit.
4 Led nº4 (Indicator of high voltage in batteries) lit.
5 Led nº5 (Indicator of low voltage in batteries) lit.
6 Display visualising 88.8
7 Version of the programming in ROM
8
Regulation, only floating (Mode FLO) or deep charge and floating
(Mode PbA)
9 Programmed Value: High voltage in battery Alarm
10 Programmed Value: Charge final voltage
11 Programmed Value: Maximum floating voltage
12 Programmed Value: Minimum floating voltage
13 Programmed Value: Output floating Voltage
14 Programmed Value: Consumption restart Voltage
15 Programmed Value: Alarm of low voltage in battery
16 Programmed Value: Consumption unplugging Voltage
17 Capacity of the accumulator system
18 Factor probing NTC
19 Handling Value: High voltage in battery Alarm
20 Handling Value: Charge final voltage
21 Handling Value: Maximum floating voltage
22 Handling Value: Minimum floating voltage
23 Handling Value: Output floating Voltage
24 Handling Value: Consumption restart Voltage
25 Handling Value: Alarm of low voltage in battery
26 Handling Value: Consumption unplugging Voltage
27 Counter of the historic operations
28 Counter of unplugging
29 Counter of floating
30 Counter of low voltage alarms
31 Conduction panel lines and subsequent cut (2 sec. approx.)
32 Consumption unplugging and subsequent restart (2 sec. approx.)
33 Display visualising 'Fin'
Function Measure
Installation I charge
Date Hour I unplugging
Data taken by Battery voltage
DIGITAL CHARGEREGULATOR LEO1
14
MU-12-L
