www.atkinsonelectronics.com Circuit Board Division
800.261.3602 Revised 05/19
Description
PVCM40D-MPT
Mounting Holes: Accepts a #8 sheet metal or wood screws.
¼” Brass Bolt: Connects to the + battery terminal wire.
¼” Brass Bolt: Connects to the + solar (PV) panel wire.
¼” Push on Spade Connector: Connects to the – battery terminal or wire.
Battery Type Dip Switch: Select your battery type.
RJ-45 Jack: Power and signal connection point for the SEDM6-40 display module.
(Requires Cat-5 patch cable).
Charge & Battery Status LED’s: Charge mode LED indicates the charging stage. The
charge type LED indicates the type of charge: soft, bulk, absorption, float, equalization
boost. The Battery status LED indicates the level of charge: 6 levels from full to empty.
SEDM6-40
Display Processor: Microprocessor controls all display and read-out functions.
Battery Voltage Adjust P1: Displays battery voltage adjustment potentiometer. Set
during step 2 of SEDM6-40 installation.
Solar Voltage Adjust P2: Displays solar voltage adjustment potentiometer. Set during
step 3 of SEDM6-40 installation
RJ-45 Jack: Power and signal connection point to PVCM40D-MPT charge controller
module. Requires Cat-5 patch cable.
Cable Error LED: Lights when a crossover cable is connected.
3 Digit Backlit LCD Display: Lights for 15 seconds every time the select button is
pressed
Mode Select Button: Allows user to change display read out, reset solar Amp hour
accumulator, and lock display setting.
Selection Indicators: Indicates which of 6 readings is displayed.
2
