Atlantic Technology FS-7.1 User Manual

Instruction Manual
7
Receiver Setup
Setting the Delay Levels on Your Receiver
Speaker Radiation Pattern
Front
Left
Center Front
Right
Setting the 'Distance/Delay Time'
on your receiver
Front Left, Center, Right Channels–enter "10 feet,”
for example. Surround Channels–set the same
distance as the front channels.
Surround Channels
Front Channels
10 feet, in this example
Front
Left
Center
Front
Right
FS-7.1 delivers 3-dimensional sound
from single enclosure
Side Surround Channel
Back Surround Channel
