Atlantic Technology FS-7.1 - System Wiring

Instruction Manual
9
LEFTCENTERRIGHT
LEFT
SURROUND
RIGHT
SURROUND
LEFT
BACK
RIGHT
BACK
RIGHT BACK
RIGHT SIDE RIGHT FRONT CENTER LEFT FRONT LEFT BACKLEFT SIDE
System Wiring
System Wiring
Be sure to connect red (+) on the speaker to
red (+) on the amplifier and black (–) on the
speaker to black (–) on the amplifier.
If using a 7.1 channel receiver
