InstallationManual
26
1.2 Vertical water heater on pedestal (VS)
150
litres
200
litres
250
litres
250
litres
300
litres
300
litres
Voltage(V)
230 V monophase
Resistor
Directhea-
tingelement
Directhea-
tingelement
Directhea-
tingelement
ceramic
Directhea-
tingelement
ceramic
Power(W) 1650 2200 3000 3000 3000 3000
Dimensions
(mm)
Ø 530 530 530 530 570 570
H 1170 1485 1805 1805 1765 1765
A 300 300 300 300 300 300
B 600 600 600 600 640 640
Heatingtime* 4h46 4h41 4h40 5h02 5h53 5h53
Qpr(Maintenance
consumption)**
1,53 1,45 2,15 2,15 2,58 2,58
V40(Quantityofhot
waterat40°C(litres))
259 358 477 477 569 569
Emptyweight(kg) 37 43 57 58 65 68
200
litres
250
litres
300
litres
500
litres
Voltage(V)
230/400 V3~ power supply (1)
Resistor
Directhea-
tingelement
Directhea-
tingelement
Directhea-
tingelement
Directhea-
tingelement
Power(W) 2200 3000 3000 5000
Dimensions
(mm)
Ø 530 530 570 680
H 1485 1805 1765 2000
A 300 300 300 255
B 600 600 640 770
Heatingtime* 4h41 4h40 5h53 5h53
Qpr(Maintenance
consumption)**
1,45 2,15 2,58 4,00
V40(Quantityofhot
waterat40°C(litres))
358 477 569
Emptyweight(kg) 44 57 68 144
*Heatingtimeforheatingbetween15
and65°C
**MaintenanceconsumptioninkWhfor
24hoursforwaterat65°C(ambient
20°C)
(1)Devicessuppliedreadyforusewith
threephase230/400V3~,possibleto
changeonsitetosinglephase230V~
Hot water
Cold water
View from above
