To Next PageTo Next PageWhy doesn't my Atlantic Heater work and the signal lamps are all off?
If your Atlantic Heater isn't working and all the signal lamps are off, it could be due to a lack of power. First, try turning it on again using the circuit breaker. If that doesn't work, press the power button on the appliance. If the issue persists, contact After Sales service or your installer.
Why is my Atlantic Panama 1000 not heating or cooling sufficiently?
If your Atlantic Heater isn't heating or cooling enough, first ensure you're in COMFORT mode. Also, check that the heater is only heating one room by keeping the door closed. Remove anything that might be blocking the appliance. Adjust the thermostat if it's set too high for cooling or too low for heating by pressing the appropriate buttons. If there's no filter located under the appliance, contact After Sales or your installer. If the problem continues, contact After Sales and ask your installer to check the weather-dependent set-point parameters.
Why doesn't my Atlantic Panama 1000 Heater heat?
If your Atlantic Heater isn't heating, make sure the COMFORT mode is activated. Check that the circuit breakers or load-shedding device (if applicable) haven't cut off the heater's power. Also, verify the room's air temperature; if it's too high, the heater won't activate.
What to do if there is smoke or an unpleasant smell from my Atlantic Heater?
If you notice smoke or an unpleasant smell coming from your Atlantic Heater, this could indicate a component failure, power surge, or electrical overload. Immediately turn off the power to the unit and contact After Sales service for assistance.
Why does my Atlantic Panama 1000 Heater heat all the time?
If your Atlantic Heater is constantly heating, ensure it's not positioned in a drafty area and that the temperature settings haven't been inadvertently altered. There might also be a fluctuation in the electrical network. Try cutting off the heater's power supply (fuse, circuit breaker) for about 10 minutes, then turn it back on. If the problem persists frequently, have your power supply checked by your energy distributor.
What does it mean when the signal lamp lights up on my Atlantic Heater?
If the signal lamp on your Atlantic Heater lights up, this indicates that you need to clean the filter located under the appliance, as well as the grid at the bottom front.
Why is my Atlantic Heater so noisy?
If your Atlantic Heater is noisy, the filter may be dirty, so clean the air filter. Also, remove any obstructions in front of the appliance. If the noise is due to water circulating, this is a normal part of the installation and not a fault. If the fan is always at maximum speed, ask your installer to adjust the weather-dependent setpoint parameters. If the noise persists, contact After Sales.
Why are there dirty marks on the wall around my Atlantic Panama 1000 Heater?
If you see dirty marks on the wall around your Atlantic Heater, it's usually due to poor air quality. Ensure the room is properly ventilated, the air is clean, and avoid smoking indoors. These marks do not qualify for a warranty replacement.
Why does the heating signal lamp appear on the screen when the Atlantic Heater is in Eco mode?
This is normal. Your Atlantic Heater may heat to maintain the Eco temperature.
Why does my Atlantic Panama 1000 continue to heat when the window is open?
There may be a slight delay between opening the window and the Atlantic Heater stopping heating. If the delay is too long, you can manually stop the appliance from heating.
General| Heating Power | 1000 W |
|---|---|
| Voltage | 230 V |
| Frequency | 50 Hz |
| Heating Area | 10-15 m² |
| Safety Features | Overheat Protection, Tip-over Switch |
| Weight | 3.5 kg |
| Type | Convection Heater |
| Thermostat | Adjustable |
Detailed technical specifications for the Panama radiator models.
Defines the minimum and maximum operating parameters for the appliance.
Crucial safety instructions to prevent injury and ensure proper use of the appliance.
Guidelines and rules for the initial placement and preparation of the appliance.
Guidance on positioning the appliance for optimal connection of water and power supplies.
Instructions for marking and preparing the wall for the appliance's mounting bar.
Step-by-step guide on how to mount the appliance onto the wall-mounted fixing bar.
Detailed instructions and wiring diagrams for connecting the appliance to the power supply.
Procedures for connecting the appliance to the heating system's water circuit.
Automatic temperature adjustment based on room occupancy for energy savings.
Procedure to adjust the displayed temperature for accurate room readings.
A guide to identifying and resolving common issues with the appliance.
