Atlantic SOLIUS - Installation Procedures; Bathroom Installation Zones; Mounting Bracket Installation

20
50
50
12
25
25
Comply with the minimum clearance
Comply with the minimum clearance
distances for positioning of the
de-
vice.
Do not install a shelf above vertical
Do not install a shelf above vertical
devices.
Installing mobile appliance
Installing mobile appliance
WARNING: The appliance must be positioned on a horizontal surface.
Refer to the installation instructions of the feet kit (ref 517000).
Volume 1
No electrical device
Volume 2
Class II IPX4 electrical de
-
vice (
Norme EN 60335-2-43
: 2003/A2 : 2008
)
INSTALLATION
Release the appliance’s hook-on bracket
:HUHFRPPHQGWKDW\RXSODFHWKHDSSOLDQFHÁDWIDFHGRZQ
Fix the hook-on bracket
