Atlas Copco DD User Manual

2904 0108 04 75
DD - DDP - PD - QD : 9 - 17 - 32
Notes
1. Included in the element kit.
2. Optional.
3. Not on the QD filters.
4. Only on DD and PD filters.
5. Only on DDp and QD filters.
6. 230V 50/60Hz not on DDp and QD filters.
7. 115V 50/60Hz not on DDp and QD filters.
8. 24V 50/60Hz not on DDp and QD filters.
8
20
10
22
21
9
25
6
4
2
12
7
26
1
5
3
24
6
23
11
28
27
DD - DDp - PD - QD : 9 DD - DDp - PD - QD : 17 DD - DDp - PD - QD : 32
Ref. Part Number Note Qty Ref. Part Number Note Qty Ref. Part Number Note Qty Designation
– 8102 2600 00 – 8102 2600 42 – 8102 2600 83 DD filter complete, G
– 8102 2604 48 – 8102 2604 89 – 8102 2605 21 DD filter complete, NPT
– 8102 2600 26 – 8102 2600 67 – 8102 2601 09 DDp filter complete, G
– 8102 2604 63 – 8102 2605 05 – 8102 2605 47 DDp filter complete, NPT
– 8102 2600 18 – 8102 2600 59 – 8102 2600 91 PD filter complete, G
– 8102 2604 55 – 8102 2604 97 – 8102 2605 39 PD filter complete, NPT
– 8102 2600 34 – 8102 2600 75 – 8102 2601 17 QD filter complete, G
– 8102 2604 71 – 8102 2605 13 – 8102 2605 54 QD filter complete, NPT
– 2901 0520 00 – 2901 0613 00 – 2901 0526 00 DD and DDp element kit
– 2901 0521 00 – 2901 0524 00 – 2901 0527 00 PD element kit
– 2901 0614 00 – 2901 0525 00 – 2901 0528 00 QD element kit
1– 11– 11– 1Head
2– 12– 12– 1Bowl
3–
1
13 –
1
13 –
1
1 Filter element
4 0663 9868 00
1
1 4 0663 9868 00
1
1 4 0663 9868 00
1
1 O-ring, 57,2x3
5 0663 2101 80
1
2 5 0663 2101 80
1
2 5 0663 2101 80
1
2 O-ring for filter, 20x2
6 0663 2111 29
1
1 6 0663 2111 29
1
1 6 0663 2111 29
1
1 O-ring, 18x3,5
7 1617 7046 00 1 7 1617 7046 00 1 7 1617 7046 00 1 Nut, G3/8”
8 1617 7048 00
3
1 8 1617 7048 00
3
1 8 1617 7048 00
3
1 Differential press. indicator
9 1617 7269 00
2/3
1 9 1617 7269 00
2/3
1 9 1617 7269 00
2/3
1 Differential press. gauge
10 – 1 10 – 1 10 – 1 Identification label
11a 8055 2164 47
2
1 11a 8055 2164 47
2
1 11a 8055 2164 47
2
1 Potential free contact
Normally open
11b 8055 2164 88
2
1 11b 8055 2164 88
2
1 11b 8055 2164 88
2
2 Potential free contact
Normally closed
12 0690 1104 01 2 12 0690 1104 01 2 12 0690 1104 01 2 Atlas Copco decal
20 8092 2429 68
2
20 8092 2429 68
2
20 8092 2429 68
2
Wall mounting kit
21 8092 2430 16
2
21 8092 2430 16
2
21 8092 2430 16
2
Serial connection kit
22 • 0663 2100 24 1 22 • 0663 2100 24 1 22 • 0663 2100 24 1 O-ring, 26x2
23 2901 0562 00 23 2901 0562 00 23 2901 0562 00 Sight glass kit
24 2901 0563 00
4
24 2901 0563 00
4
24 2901 0563 00
4
Automatic drain valve kit
25 2901 0611 00
5
25 2901 0611 00
5
25 2901 0611 00
5
Manual drain valve kit
26 1617 7082 01
2
26 1617 7082 01
2
26 1617 7082 01
2
Male coupling, G 1/8”
26 1617 7082 02
2
26 1617 7082 02
2
26 1617 7082 02
2
Female coupling, G 1/8”
26 1617 7082 03
2
26 1617 7082 03
2
26 1617 7082 03
2
Hose connection
27 8055 2600 64
2/3
1 27 8055 2600 64
2/3
1 27 8055 2600 64
2/3
1 Dual pressure transmitter
28 8055 2600 31
2/6
1 28 8055 2600 31
2/6
1 28 8055 2600 31
2/6
1 EWD Connection
28 8055 2600 49
2/7
1 28 8055 2600 49
2/7
1 28 8055 2600 49
2/7
1 EWD Connection
28 8055 2600 56
2/8
1 28 8055 2600 56
2/8
1 28 8055 2600 56
2/8
1 EWD Connection
A080-070401-010
Vendor Manual Atlas Copco A090-070423-004 PD & DD Filters Instruction Manual
Q-Pulse Id VM260
Active 09/09/2013
Page 77 of 90
