Atlas Copco GHS 585 VSD+ - Page 107

Instruction book
6996 0227 40 107
Installation method C according to table B.52.1.
Single-core or multi-core cable on a wooden wall.
Maximum allowed current in function of the ambient temperature for installation method C.
Installation method F according table B.52.1. Single-core cables,
touching in free air Clearance to wall not less than one cable diameter
Maximum allowed current in function of the ambient temperature for installation method F
