Instruction book
6996 0227 40 41
The first line of the screen is highlighted. Use the Scroll keys (1) to highlight the setting to be modified
and press the Enter key (2). Following screen appears:
The upper and lower limit of the setting is shown in grey, the actual setting is shown in black. Use the up
or down key of the Scroll keys to modify the settings as required and press the Enter key to accept.
If necessary, change the other settings as required in the same way as described above.
Indirect stop: occurs when the pressure decreases to the pre-set Indirect stop setpoint (= setpoint minus
Indirect stop level). The motor will decelerate to minimum speed and the inlet valve will close.
Both settings (Indirect stop level and direct stop level) are programmable, see section Programmable
settings.
3.12 Event history menu
Control panel
