GX 2 up to GX 5 Full-Feature on 200 l receiver
(1) Cooling air outlet
(2) Cooling air inlet
(3) Compressed air outlet
(4) Power supply cable
(5) Dryer, cooling air inlet
(6) Dryer, cooling air outlet
(7) External box (only on GX 5 EP 230/1/60 and on all GX 7 EP)
(8) Location of the centre of gravity (G)
Instruction book
36 2920 7105 31
