Atlas Copco GX 7

Ref. Name
1 Control panel
AF Air filter
AO Air outlet
AR Air receiver
Ca Air cooler
Co Oil cooler
Da Automatic drain
Dm1 Manual condensate drain
DR Dryer
E Compressor element
OF Oil filter
OS Oil separator
OT Oil separator tank
GX Full-feature
An air cooler (Ca) and an air dryer (DR) are integrated into the bodywork. A condensate drain system is
provided including a valve for automatic draining during operation (Da) and a manual drain valve (Dm1).
GX Pack
The compressor is not fitted with an air cooler, air dryer and condensate drain system as standard.
