2920 7090 00 35
Instruction book
9820 2239 91/05
81463D
LF Trolley with Petrol Engine
References of figures on dimension drawings.
Reference Designation
1
Air inlet
2
Hole, 15 x 25 (4X)
3
Cooling air inlet
4
Net mass
5
Compressed air outlet, G1/2
