Atlas Copco LF 2 User Manual

2920 7090 00 43
Instruction book
Settings of overload relay and fuses of compressors with Y-D starter
50Hz
Type
V
oltage (V) Overload relay (A) Fuses (A)
LF5 230 10 25
LF5 400 6 16
LF5 500 5 10
LF7 230 13 32
LF7 400 8 20
LF10 230 16 40
LF10 400 10 25
LF10 440 9 20
LF10 500 7 20
LF10 550 6 16
LF10 690 4 10
60Hz
Type Voltage (V) Overload relay (A) Fuses (A)
LF5 230 10.5 25
LF5 380 6.5 16
LF5 460 5.5 16
LF7 230 14 32
LF7 380 8.5 20
LF7 460 7 16
LF10 230 16 40
LF10 380 10.5 25
LF10 460 9 20
