Instruction book
Texts on figures 2.1 up to 2.20
(1) Air inlet
(2) Hole, 15 x 25 (4x)
(3) Cooling air inlet
(4) Net mass
(5) Compressed air outlet, G 1/2
(6) Manual condensate drain
(7) Hole, 15 x 25 (3x)
(8) Receiver
(9) Cooling air outlet
(10) Motor cooling air inlet
(11) Compressed air outlet
(12) Hole, 15 x 24 (4 x), can be used for fixing without rubber pads
(13) Compressor cooling air and air inlet
(14) For dismantling air filter
(15) Compressor air outlet with flexible (2 meter)
(16) Electric cable entry (on rear side)
(17) Hole (4x)
(18) EURO receiver
(19) Air outlet
2920 1585 00 - 35 -
