Atlas Copco QAX 12 Dd S2 APP User Manual

- 80 -
Alternator Standard IEC 34-1
ISO 8528-5
Make Leroy Somer
Model LSA 40 M5
Rated output, class H temp. rise 25 kVA
Degree of protection IP 23
Insulation stator class H
Insulation rotor class H
Number of wires 12
Engine Standard ISO 3046
ISO 8528-2
Type DEUTZ F3M 2011 F
Rated net output 22.6 kW
Coolant oil
Combustion system direct injection
Aspiration natural
Number of cylinders 3 - in line
Swept volume 2.33 l
Speed governing mechanical
Capacity of oil sump 5.5 l
Capacity of cooling system 8 l
Electrical system 12 Vdc
Emission compliance Tier 2
Power circuit Circuit-breaker, 3-phase (only ouside of USA)
Number of poles 4
Thermal release It 63 A
Magnetic release Im 3..5xIn
