Atlas Copco QES 9-11 Kd ESF - Page 90

- 90 -
Outlet sockets (optional)
domestic (1x)
(optional)
domestic (1x)
(optional)
2p + PE 2p + PE
16 A 230 V 16 A 230 V
CEE form (1x) CEE form (1x)
3p + N + PE 2p + PE
16 A 400 V 16 A 230V
CEE form (1x)
3p + N + PE
32 A 400 V
Unit Dimensions (LxWxH) 1.75x0.84x1.12 m 1.75x0.84x1.12 m 1.75x0.84x1.12 m 1.75x0.84x1.12 m
Weight net mass 720 kg 720 kg 720 kg 720 kg
