- 67 -
Setting the ON and OFF triggers of the timer
To program the ON trigger proceed as follows:
To program the OFF trigger follow the menu flow
above and select OFF after selecting ‘SWITCH’.
pulse off
copy
When both the photocell and the
timer option are installed, the
lamps of the light tower will
switch on/off, depending on which
of both options triggers first.
