XAHS365 Md
26
The road signalisation is in conformity with EEC 76/756,
amendment 91/663 and ECE R48-00.
Refer to page 438, 440, 442 and 444.
A
XLES AND ADJUSTABLE TOWBAR FOR TANDEM
(
WITH PNEUMATIC BRAKES
)
The compressors, mounted on a tandem undercarriage with
adjustable towbar allow an optimal towing and manoeuvrability.
The axles and adjustable towbar should always be installed in
combination with the pneumatic brakes and road signalisation,
allowing the compressor to be used for high speed towing on main
roads.
Refer to page 407 and 413.
A
FTERCOOLER
,
WATERSEPARATOR AND FINE FILTER
The aftercooler, waterseparator and fine filter are provided to
decrease the temperature of the outlet air and to remove any
residual oil and moisture in the outlet air.
The aftercooler cools the outlet air. The condensation formed by
the cooling is separated by the waterseparator. Any final oil and
humidity is eliminated by the fine filter.
A pressure decrease will appear due to the installation of the
aftercooler, waterseparator and fine filter. The pressure gauge
indicates the pressure in front of the aftercooler. As a result, the
outlet pressure will always be a little less than the pressure
indicated.
Refer to page 450.
A
FTERCOOLER
,
WATER
-
AND OILSEPARATOR
,
FINE
FILTER AND REHEATER
The aftercooler, water- and oilseparator, fine filter and reheater are
provided to remove any residual moisture in the outlet air and to
keep the outlet air on constant temperature avoiding the formation
of condensation in the pipes or hoses.
The aftercooler cools the outlet air. The condensation formed by
the cooling is separated by the waterseparator and any final
humidity and oil is deleted by the fine filter. The air is reheated
afterwards.
A pressure decrease will appear due to the installation of the
aftercooler, waterseparator and fine filter. The pressure gauge
indicates the pressure in front of the aftercooler. As a result, the
outlet pressure will always be a little less than the pressure
indicated.
Refer to page 451.
